Hanwha ACO-6020R Dubai

Hanwha Vision ACO-6020R is a 2MP Analog HD infrared bullet camera with 1920×1080 video at up to 30 fps, a 3.6 mm fixed lens, selectable AHD/TVI/CVI/CVBS output, infrared viewing up to 25 metres, IP67 weather protection and IK10 impact resistance. It is suited to fixed-view DVR surveillance projects, including coax-based upgrades where recorder compatibility is confirmed.

Request a Quote

Quick Product Summary

The ACO-6020R combines Full HD analog video, multi-format output and rugged construction for businesses that need a simple fixed-lens bullet camera. It uses a 1/3-inch CMOS sensor, 3.6 mm F1.6 lens, approximately 78° horizontal view, automatic day/night switching and 12 VDC power.

Key Features and Benefits

• 1920×1080 resolution at up to 30 fps.
• Selectable AHD, TVI, CVI and CVBS BNC video output.
• 3.6 mm fixed lens, F1.6, approximately 78° horizontal view.
• Infrared viewing distance up to 25 m.
• Auto ICR day/night, BLC, DWDR and 2D+3D noise reduction.
• IP67 weather resistance and IK10 impact resistance.
• 12 VDC operation with maximum specified consumption of 3.6 W.

Verified Technical Specifications

Compatibility and Deployment Guidance

Before ordering, confirm the DVR brand and model, supported analog HD format, 1080p channel capability, cable condition and 12 VDC power design. The camera can be useful in coax-based upgrades, but multi-format output does not guarantee compatibility with every recorder. The fixed 3.6 mm lens cannot be optically zoomed, so scene width and mounting distance should be checked before installation.

Ideal Applications

Suitable use cases include office entrances, shop fronts, warehouses, service yards, parking approaches, school perimeters, apartment service zones, villas and other locations where a fixed-view analog HD bullet camera is appropriate.

What to Confirm Before Ordering

• DVR compatibility and required output standard.
• Camera quantity and available recorder channels.
• Existing coax cable condition and run length.
• 12 VDC power capacity and voltage drop.
• Whether the 3.6 mm fixed lens matches the target scene.
• Night identification distance and ambient lighting.
• Mounting, cable sealing, backbox and surge protection requirements.
• Required recording retention and storage capacity.

Hanwha ACO-6020R Dubai

Dubai customers commonly evaluate the ACO-6020R for CCTV upgrades where usable coax cabling is already installed or where a straightforward DVR-based system is preferred. Its 2MP Full HD output is suitable for general monitoring at entrances, service corridors, parking access points, loading areas and perimeter positions. Because the lens is fixed at 3.6 mm, installers should validate the proposed viewing angle before mounting rather than treating the camera as an adjustable zoom model.

Outdoor Dubai installations should also account for exposure, cable routing and protected terminations. IP67 and IK10 are valuable enclosure specifications, but correct installation remains essential. The stated 25 m IR range supports night surveillance at many near-field positions, although actual identification detail depends on target size, mounting height, reflectivity and ambient lighting. Fourteck can assist with DVR matching, quantity planning, storage, power and accessory requirements. Visit Fourteck UAE or contact Fourteck for a current quotation.

Hanwha ACO-6020R UAE

Across the UAE, the ACO-6020R can fit branch upgrades, warehouse surveillance, retail projects and other locations where analog HD remains practical. Different sites may use different DVR generations, so procurement teams should document recorder models and supported signal types before standardising the camera across multiple emirates. The camera’s selectable AHD, TVI, CVI and CVBS output gives useful flexibility, but each recorder still needs to be checked.

For new projects, buyers should compare analog HD with IP cameras before deciding on a long-term platform. Existing coax may favour the ACO-6020R, while new sites requiring PoE, advanced analytics or network-based VMS integration may be better served by IP surveillance. UAE enquiries can be routed through Fourteck UAE.

Hanwha ACO-6020R Kenya

Kenya organisations can consider the ACO-6020R when existing coax infrastructure remains usable and a 2MP DVR-based upgrade is preferred. Offices, schools, retail outlets, warehouses and compounds should confirm recorder support, scene distance and night requirements before choosing quantities. The fixed 3.6 mm lens suits general coverage but may not provide sufficient detail for distant gates or large yards.

Power design should include camera load, cable length, DVR operation and any backup-power requirement. Outdoor terminations should be protected even with an IP67 camera enclosure. Regional enquiries can be made through Fourteck Kenya.

Hanwha ACO-6020R Kuwait

Kuwait buyers should consider recorder support, heat exposure, dust, cable protection and viewing distance when specifying the ACO-6020R. The camera is rated for operation up to +55°C and carries IP67 weather protection, but installation location and direct environmental exposure still require engineering judgement. The selectable output formats are helpful for DVR retrofits, while the fixed lens is best for known scene geometry.

For warehouse, compound and commercial entrance projects, verify whether the 25 m IR specification and 78° horizontal view are appropriate. Visit Fourteck Kuwait for regional purchasing and project enquiries.

Hanwha ACO-6020R Ghana

Ghana businesses may use the ACO-6020R for analog CCTV upgrades where replacing usable coax is unnecessary. The camera can be considered for retail, education, warehousing, offices, hospitality and compound surveillance, provided the DVR supports the chosen signal type. Storage, power backup and cable quality should be reviewed together rather than treating the camera as a standalone purchase.

Outdoor installations need protected connectors and maintainable cable routing. Where longer-range identification or advanced analytics are required, an alternative camera should be considered. Regional buyers can contact Fourteck Ghana.

Hanwha ACO-6020R Uganda

Uganda sites with serviceable coax cabling can use the ACO-6020R as part of a practical Full HD DVR refresh. Typical locations include offices, shops, schools, hotels, clinics, warehouses and compounds. Buyers should compare the required view with the fixed 3.6 mm lens and assess whether 25 m IR illumination is appropriate for the real night scene.

The 12 VDC system should be sized for cable distance and total camera count, and backup power planning should include the recorder and networking used for remote viewing. Regional product enquiries can be made through Fourteck Uganda.

Hanwha ACO-6020R Nigeria

Nigeria surveillance projects can use the ACO-6020R for 2MP analog HD coverage in sites that want to retain coax infrastructure. Warehouses, offices, retail branches and compounds should first confirm DVR compatibility and determine whether the fixed 3.6 mm lens gives adequate subject detail at the required distance. Sites needing analytics, PoE or centralized VMS should compare IP alternatives.

Power continuity and surge protection can be important system-design considerations, especially when recording availability matters. Fourteck can help customers compare camera, DVR, storage and installation requirements. Visit Fourteck Nigeria for regional enquiries.

Hanwha ACO-6020R Seychelles

Seychelles customers may consider the ACO-6020R for hospitality, office, retail, storage and compound surveillance where analog HD is the preferred architecture. Coastal conditions make protected terminations, cable management and periodic inspection important even when using an IP67-rated camera. The fixed lens should be matched to each entrance, service area or perimeter position before purchase.

For island projects, camera quantity, DVR compatibility, power and spare-parts planning should be reviewed together. Seychelles-related enquiries can be directed through Fourteck Africa.

Related Fourteck Resources

• CCTV Installation Dubai & UAE — surveillance design, installation and deployment guidance.
• CCTV & Access Control Systems UAE — broader security-system planning.
• Fourteck UAE — UAE product and project enquiries.
• Fourteck Kenya — Kenya regional enquiries.
• Fourteck Kuwait — Kuwait regional enquiries.
• Fourteck Ghana — Ghana regional enquiries.
• Fourteck Uganda — Uganda regional enquiries.
• Fourteck Nigeria — Nigeria regional enquiries.
• Fourteck Africa — Africa and Seychelles-related enquiries.

Frequently Asked Questions

What resolution is the ACO-6020R?

It provides 1920×1080 Full HD video at up to 30 fps.

Which analog formats are supported?

The BNC output is selectable between AHD, TVI, CVI and CVBS, subject to DVR compatibility.

How far does the IR reach?

The specified IR viewing distance is up to 25 metres.

Is it suitable outdoors?

The camera carries IP67 weather protection and IK10 impact resistance, with correct outdoor installation still required.

Does the lens zoom?

No. It uses a fixed 3.6 mm lens.

Can it use existing coax?

It can often be used in coax-based retrofits if cable condition is good and the DVR supports the selected signal type.

How is it powered?

The camera uses 12 VDC power, with a specified maximum consumption of 3.6 W.

Which backbox is listed for the model?

Hanwha specifies the SBV-A14B backbox.

Is this an IP camera?

No. ACO-6020R is an analog HD camera intended for DVR-based surveillance.

How do I request pricing in Dubai?

Send Fourteck the required quantity, DVR model and project requirements so current pricing and availability can be confirmed.
